Truck Mounted Crane SQ8SK3Q 28KW Telescopic Canes Truck with Telescopic boom
Product Description
1. Truck Mounted Crane Have Throttle Control System
Changing the form of previous manipulation and throttle operation individually,Realization of the bilateral handle synchronous and driving throttle acceleration and deceleration automatically, due to the speed change steady,it can easily to carry out the lifting work.
2. Truck Mounted Crane SQ8SK3Q position automatic hook device
Maximum savings in preparation time before and after operation, to ensure that customer's vehicle could be in a driving state in the shortest time, and prevent crane damage accident caused by hoist swing to enhance the safety of driving.
3. Hoisting overwinder device
If a user is negligent or unfamiliar with the operation of lifting hooks,the hoisting overwinder device will stop hook raise in time, to prevent the safety of personal and property caused by fracture of wire rope.
Advantage
1. Slewing locking device
Slewing locking device can ensure that the lifting arm does not sway because of the centrifugal force during the driving and steering process of the vehicle,to avoid all kinds of accidents caused by swaying.
2. Truck Mounted Crane SQ8SK3Q 28KW Engineering Cane Truck Dual pump converging
The hydraulic system adopts dual high pressure gear pump, multi-way valve hoisting joint to realize the converging, to improve the speed of winch, at the same time, it can realize the compound action of crane.
3. Truck Mounted Crane SQ8SK3Q 28KW Engineering Cane Truck Torque limiter
It can select torque limit overload protection device to prevent users because of negligence or unfamiliar with the lifting operation principle of overload operation, thereby causing the vehicle rollover and crane damage accidents.
4. Truck Mounted Crane SQ8SK3Q 28KW Engineering Cane Truck with high quality
5. TheTruck Mounted Crane SQ8SK3Q are very popular in African countries
Main Parameter of Truck Mounted Crane SQ8SK3Q 28KW Telescopic Canes Truck
| Model | XCMG SQ8SK3Q | Unit | |
| Max Lifting Capacity | 8000 | kg | |
| Max Lifting Moment | 20 | T.M | |
| Recommend Power | 28 | kw | |
| Max Oil Flow of Hydraulic System | 55 | L/min | |
| Max Pressure of Hydraulic System | 27 | MPa | |
| Oil Tank Capacity | 160 | L | |
| Rotation Angle | All Rotation | | |
| Crane Weight | 3300 | kg | |
| Installation Space | 1200 | mm | |
| Choice of Chassis | CA1176PK2L9T3A95 ; CA1170PK2L7T3EA80;
CA1240PK2L7T4EA81;HFC1202KR1K3;
EQ5161GFJ7; BJ1317VNPJJ-S5;
EQ5201GFJ6; CA1200PK2L7T3EA80;
LZ1160LCMT; DFL1250A9; BJ5317ZNPJJ-S; CA1253P7K2L11T1E ; EQ1252GFJ; | |
| |
| |
| SQ8SK3Q Lifting capability diagram | |
| Working radius (m) | 2.5 | 4.5 | 7 | 9 | 11.5 | |
| Lifting capacity (kg) | 8000 | 4400 | 2500 | 1750 | 1100 | |
| | | | | | | | |
Shipping & Delivery
We supervise the process from the factory to the port designated by the customer to ensure that the customer's products arrive at the destination accurately and safely.The Truck Mounted Crane SQ8SK3Q in nude by RO-RO or bulk.
More photo for your reference
